SP UD90 2230 PCIe Gen 4x4 NVMe™ SSD

• Perfect Fit for Portability
• Small Yet Mighty
• Ample Storage for All Your Needs
• Reliable Storage Made Simple

Expand

Product Introduction
Product Specifications
File Download
Purchase

Perfect Fit for Portability

Elevate your storage and power up the performance on-the-go with our compact M.2 2230 UD90. Easy to install and fully compatible with handheld gaming PCs, tablets, ultrabooks, lightweight notebooks, mini PCs, and other small form factor devices. Upgrading has never been smoother or more hassle-free!

Small Yet Mighty

Ample Storage for All Your Needs

Say goodbye to storage limitations. The UD90 2230 offers massive storage capacity of up to 2 TB, allowing you to store your entire game collection and a vast array of work files, videos, photos, and more. Whether you're embarking on thrilling gaming adventures or managing your professional endeavors, this versatile storage solution ensures that you never miss a beat.

Reliable Storage Made Simple

The Built-in data security and error-correction capabilities ensure the integrity of your information and provide a reliable storage solution. Our user-friendly SP Toolbox offers effortless access to drive information and maintenance, providing comprehensive data protection and accuracy.

P/N	Capacity	Dimensions	Weight	Interface	Connectors	Performance Read	Performance Write	Material	Color	Supported OS	System Requirement	Operating Temperature	Patent	MTBF-est	Certification	Warranty	Extra Protection	Product Feature	⇅ Compare
SP500GBP44UD9007	500GB	22.0x30.0x3.7 mm	3g	M.2 PCIe Gen 4x4	M.2 NVMe M Key	4,700MB/s	1,700MB/s	n/a	n/a	Microsoft Windows 7 / 8 / 10 / 11 Linux Kernel 2.6.31 or newer	Computer with M.2 slots supporting PCIe interface and an OS with NVMe support	0°C - 70°C	n/a	-	CE, FCC, UKCA, BSMI, Green dot, WEEE, RoHS, KCC	5-Year Limited	Shock Resistance Test(1500g/0.5ms)	Game Console Compatible	Add to compare
SP01KGBP44UD9007	1TB	22.0x30.0x3.7 mm	3g	M.2 PCIe Gen 4x4	M.2 NVMe M Key	4,900MB/s	3,200MB/s	n/a	n/a	Microsoft Windows 7 / 8 / 10 / 11 Linux Kernel 2.6.31 or newer	Computer with M.2 slots supporting PCIe interface and an OS with NVMe support	0°C - 70°C	n/a	-	CE, FCC, UKCA, BSMI, Green dot, WEEE, RoHS, KCC	5-Year Limited	Shock Resistance Test(1500g/0.5ms)	Game Console Compatible	Add to compare
SP02KGBP44UD9007	2TB	22.0x30.0x3.7 mm	3g	M.2 PCIe Gen 4x4	M.2 NVMe M Key	5,000MB/s	3,200MB/s	n/a	n/a	Microsoft Windows 7 / 8 / 10 / 11 Linux Kernel 2.6.31 or newer	Computer with M.2 slots supporting PCIe interface and an OS with NVMe support	0°C - 70°C	n/a	-	CE, FCC, UKCA, BSMI, Green dot, WEEE, RoHS, KCC	5-Year Limited	Shock Resistance Test(1500g/0.5ms)	Game Console Compatible	Add to compare

Capacity	500GB, 1TB, 2TB
Dimensions	22.0mm x 30.0mm x 3.7 mm*
Interface	PCIe Gen 4x4
Weight	3g
Performance Read(max.)	500GB: 4,700MB/s 1TB:4,900MB/s 2TB: 5,000MB/s
Performance Write(max.)	500GB:1,700MB/s 1TB: 3,200MB/s 2TB: 3,200MB/s
System Requirement	Computer with M.2 slots supporting PCIe interface and an OS with NVMe support
MTBF (est)	1,500,000 hours
Shock Resistance Test	1500G/0.5ms
Operating Temperature	0℃- 70℃
Certification	CE/FCC/BSMI/Green dot/WEEE/RoHS/KCC
Warranty	5-year limited warranty
Note	* Product size and weight may vary by configuration, manufacturing process and measurements. All specifications are subject to the actual product.**Performance read/write varies by system performance (such as hardware, software, and interface mode) and capacity.

Name

Language

File Format

Version

Last Updated

File Download

SP UD90 2230 PCIe Gen 4x4 NVMe™ SSD

PDF.

v2.0
