Cfexpress Type B

• Designed for next-gen video/photo cameras such as DSLR, cinema, and mirrorless cameras
• Professional-level performance with high-speed PCIe Gen 3x2 interface
• Incredible read speeds up to 1,800MB/s and write speeds up to 1,600MB/s
• Captures flawless RAW videos and photos in breathtaking 8K Ultra HD resolution
• Massive storage capacity options up to 2TB
• Backwards-compatible with XQD cameras and camcorders that adopt firmware enabling CFexpress Type B
• Power Loss Shield protects the card's data in the event of a sudden power loss
• Smart Power Saver helps preserve the host's battery life and the card's endurance
• Auto Temp Adapter regulates the temperature of the card to prevent overheating and maintain sustained performance
• Equipped with an automatic error correction code (ECC) function

Expand

Product Introduction
Product Specifications
Purchase

Unparalleled Performance For The Best Shots

When you're out there capturing the action in the midst of the moment, you need a card that doesn't compromise between performance, capacity, and durability. This CFexpress Type B card makes use of its high-speed PCIe Gen 3x2 interface to deliver professional-level performance coupled with ultra-high capacities and reliable operation

Push The Limits Of Your Camera

Give your CFast 2.0 and XQD form factor cards a rest -- this CFexpress Type B card is more than 3 times faster. It's designed for high-end, next-gen devices such as cinema cameras and DSLR cameras to leverage their maximum performance and capture the highest bit-rate and frame-rate RAW videos and photos.

Pro-Level Quality With 8K Video

With its high-speed PCIe Gen 3x2 interface delivering low latency, this card enables smooth video capture on your devices in breathtaking 8K Ultra HD resolution. Get flawless recordings with crystal-clear details that are sure to wow all of your viewers, including yourself!

Speeds To Keep Up With The Action

With this CFexpress Type B card, you'll get incredible read speeds up to 1,800MB/s and write speeds up to 1,600MB/s for cinema-quality videos and magazine-quality photos. With these speeds, uncompressed continuous RAW capture of fast-moving action is a breeze and transfers are completed in the blink of an eye.

Storage That Won't Slow You Down

Don't let your memory card slow you down by having to swap cards mid-shoot. With massive storage capacities up to 2TB, you'll have plenty of space to keep capturing without interruption. That means tons of room for the highest bit-rate RAW videos and photos, but all within a tiny CFexpress Type B form factor.

Protection From 3 Safety Mechanisms

Auto Temp Adapter: regulates the temperature of the card during increased temperature conditions such as heavy workloads to prevent overheating and maintain sustained performance. Smart Power Saver: helps preserve the host's battery life and the card's endurance by managing power usage efficiently and effectively. Power Loss Shield: protects the card's data in the event of a sudden power loss by triggering a safe shutdown.

Protection From 3 Safety Mechanisms

Works With XQD Cameras, Too

For greater versatility, this card is also backwards-compatible with XQD cameras and camcorders that adopt firmware enabling CFexpress Type B. Get next-gen performance on existing devices.

Works With XQD Cameras, Too

For greater versatility, this card is also backwards-compatible with XQD cameras and camcorders that adopt firmware enabling CFexpress Type B. Get next-gen performance on existing devices.

P/N	Capacity	Performance Read	Performance Write	Dimensions	Transmission Interface	Speed Class	Weight	Durability	Operating Temperature	Operating Voltage	Warranty	Humidity	Widget Security Supports	Dust Resistance/Proof	Water Resistance Proof	Drop Proof	Shock-Proof	Temperature Proof	Xray Proof	Vibration Proof	Torque	Bending	⇅ Compare
SP512GBCFEB21V10	512GB	1800 MB/s	1200 MB/s	38.5 x 29.6 x 3.8 mm	PCIe Gen 3x2	n/a	7g	n/a	-10°C - 70°C	3.3V	3-Year Limited	n/a	◯	✕	✕	80cm	1500G	✕	✕	◯	✕	◯	Add to compare
SP001TBCFEB21V10	1TB	1800 MB/s	1600 MB/s	38.5 x 29.6 x 3.8 mm	PCIe Gen 3x2	n/a	7g	n/a	-10°C - 70°C	3.3V	3-Year Limited	n/a	◯	✕	✕	80cm	1500G	✕	✕	◯	✕	◯	Add to compare
SP002TBCFEB21V10	2TB	1800 MB/s	1600 MB/s	38.5 x 29.6 x 3.8 mm	PCIe Gen 3x2	n/a	7g	n/a	-10°C - 70°C	3.3V	3-Year Limited	n/a	◯	✕	✕	80cm	1500G	✕	✕	◯	✕	◯	Add to compare
SP256GBCFEB21V10	256GB	1800 MB/s	600 MB/s	38.5 x 29.6 x 3.8 mm	PCIe Gen 3x2	n/a	7g	n/a	-10°C - 70°C	3.3V	3-Year Limited	n/a	◯	✕	✕	80cm	1500G	✕	✕	◯	✕	◯	Add to compare

Capacity	256GB, 512GB, 1TB, 2TB
Dimensions	38.5mm x 29.6mm x 3.8mm
Weight	7g
Interface	PCIe Gen 3x2
Performance Read(max.)	1,800MB/s
Performance Write(max.)	600MB/s(256GB) 1200MB/s(512GB) 1600MB/s(1TB, 2TB)
Sustained Write Speed	450MB/s(256GB) 820MB/s(512GB) 1200MB/s(1TB, 2TB)
Operation Voltage	3.3V
Operating Temperature	8% - 95%
Storage Temperature	-10°C - 70°C
Warranty	-40°C - 85°C
Note	3-Year Limited Warranty
